泵規格 | 壓力 MPa | 運動粘度 mm2/s |
| 12 | 40 | 75 | 150 | 380 | 760 |
流量 L/min | 軸功率 kW | 流量 L/min | 軸功率 kW | 流量 L/min | 軸功率 kW | 流量 L/min | 軸功率 kW | 流量 L/min | 軸功率 kW | 流量 L/min | 軸功率 kW |
SN40-46三螺桿泵 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 36.2 35.0 33.8 32.6 | 0.50 0.83 1.15 1.47 | 36.9 35.7 34.5 33.3 32.4 | 0.50 0.83 1.15 1.47 1.78 | 37.2 36.4 35.6 34.7 34.0 33.2 | 0.59 0.91 1.23 1.55 1.87 2.20 | 37.5 36.9 36.3 35.6 35.1 34.4 33.9 | 0.71 1.04 1.35 1.67 1.99 2.32 2.65 | 37.9 37.4 36.9 36.5 36.1 35.7 35.3 | 0.86 1.19 1.50 1.82 2.15 2.46 2.80 | 38.0 37.6 37.2 36.9 36.7 36.4 36.0 35.7 | 1.12 1.46 1.77 2.10 2.42 2.73 3.07 3.39 |
SN40-46三螺桿泵 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 51.9 50.1 18.5 | 0.65 1.11 1.57 | 52.6 50.8 49.2 47.6 | 0.65 1.11 1.57 2.03 | 53.3 52.0 50.8 49.7 48.6 | 0.75 1.20 1.66 2.12 2.59 | 53.7 52.6 51.7 50.9 50.0 49.2 | 0.88 1.34 1.79 2.26 2.72 3.18 | 54.1 53.3 52.6 52.0 51.4 50.9 50.4 | 1.03 1.49 1.95 2.42 2.88 3.34 3.80 | 54.3 53.7 53.3 52.9 52.4 52.0 51.4 51.0 | 1.32 1.78 2.25 2.71 3.17 3.63 4.08 4.54 |
SN40-54三螺桿泵 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 68.9 | 0.81 | 70.0 67.3 | 0.81 1.43 | 71.1 69.1 67.1 | 0.90 1.52 2.13 | 71.7 70.2 68.6 67.3 | 1.03 1.65 2.28 2.89 | 72.2 71.2 70.2 69.2 68.2 | 1.19 1.81 2.43 3.05 3.66 | 72.6 71.9 71.1 70.4 69.6 69.0 | 1.48 2.09 2.72 3.34 3.95 4.57 |
SN80-36三螺桿泵 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 53.9 51.1 48.5 46.0 | 0.69 1.17 1.65 2.14 | 55.3 53.7 52.1 50.7 49.4 | 0.69 1.17 1.65 2.14 2.62 | 55.9 54.8 53.7 52.7 51.7 50.7 | 0.78 1.26 1.75 2.23 2.71 3.19 | 56.2 55.4 54.5 53.8 53.0 52.3 51.5 | 0.91 1.39 1.88 2.36 2.86 3.32 3.79 | 56.6 56.0 55.4 54.9 54.3 53.8 53.2 | 1.08 1.56 2.05 2.53 3.01 3.49 3.96 | 56.7 56.3 55.8 55.4 54.9 54.6 54.1 53.8 | 1.36 1.85 2.33 2.81 3.29 3.77 4.24 4.72 |
SN80-42三螺桿泵 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 65.2 61.3 57.7 | 0.79 1.38 1.92 | 67.3 65.1 63.1 61.2 | 0.79 1.38 1.96 2.54 | 68.1 66.5 65.1 63.7 62.4 | 0.88 1.47 2.05 2.63 3.22 | 68.6 67.4 66.3 65.3 64.3 63.4 | 1.01 1.60 2.18 2.76 3.35 3.93 | 69.0 68.2 67.5 66.8 66.1 65.4 | 1.18 1.77 2.35 2.93 3.52 4.10 | 69.2 68.6 68.0 67.5 66.9 66.4 65.9 65.5 | 1.46 2.05 2.63 3.21 3.80 4.38 4.96 5.55 |
SN80-46三螺桿泵 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 77.2 73.3 69.7 | 0.90 1.58 2.27 | 79.1 76.8 74.7 72.8 | 0.90 1.58 2.27 2.95 | 79.9 78.2 76.7 75.2 73.9 | 0.99 1.68 2.36 3.04 3.73 | 80.4 79.1 77.9 76.8 75.8 74.8 | 1.11 1.81 2.49 3.17 3.86 4.54 | 80.8 79.9 79.1 78.3 77.6 76.8 | 1.28 1.98 2.66 3.34 4.03 4.71 | 81.0 80.3 79.6 79.0 78.3 77.8 77.2 | 1.56 2.26 2.94 3.62 4.31 4.99 5.68 |
SN80-54 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 100 94.1 | 1.11 2.02 | 104 100 96.5 | 1.11 2.02 2.92 | 105 103 99.5 97.5 | 1.20 2.11 3.01 3.91 | 106 104 102 99.4 98.1 | 1.33 2.24 3.14 4.04 4.94 | 106 105 104 102 101 100 | 1.50 2.41 3.31 4.21 5.12 6.02 | 107 106 105 103 102 101 | 1.79 2.69 3.59 4.49 5.40 6.30 |
SN120-42 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 93.7 88.7 84.1 79.6 | 1.19 2.03 2.86 3.69 | 96.5 93.7 91.1 88.6 86.3 | 1.19 2.03 2.86 3.69 4.53 | 97.5 95.5 93.6 91.9 90.2 88.6 | 1.32 2.16 2.99 3.82 4.66 5.49 | 98.1 96.6 95.2 93.6 92.6 91.3 90.1 | 1.51 2.35 3.18 4.01 4.85 5.68 6.51 | 98.7 97.7 96.8 95.9 95.0 94.1 93.3 | 1.79 2.63 3.46 4.29 5.13 5.96 6.79 | 99.0 96.2 97.5 96.8 96.1 95.4 94.8 94.2 | 2.27 3.11 3.94 4.77 5.61 6.44 7.24 8.11 |
SN120-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 112 107 102 | 1.34 2.34 3.32 | 115 112 109 106 | 1.34 2.34 3.32 4.30 | 116 114 111 109 107 | 1.47 2.47 3.45 4.43 5.43 | 116 115 112 111 110 108 | 1.66 2.66 3.64 4.62 5.62 6.60 | 117 116 114 113 112 111 110 | 1.95 2.94 3.92 4.90 5.90 6.88 7.86 | 117 116 115 114 113 112 112 111 | 2.43 3.42 4.40 5.39 6.38 7.36 8.34 9.34 |
SN120-54 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 147 139 | 1.68 2.99 | 151 146 142 | 1.68 2.99 4.30 | 153 149 146 143 | 1.81 3.12 4.43 5.74 | 154 141 148 146 144 | 2.00 3.31 4.62 5.93 7.24 | 155 152 151 149 148 147 | 2.28 3.59 4.90 6.21 7.52 8.84 | 155 153 152 151 150 149 | 2.76 4.07 5.39 6.69 8.00 9.32 |
SN210-40 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 160 154 149 144 | 1.96 3.35 4.75 6.15 | 163 159 156 153 150 | 1.96 3.35 4.75 6.15 7.54 | 164 161 159 157 155 153 | 2.14 3.53 4.93 6.33 7.72 9.12 | 165 162 161 159 158 156 155 | 2.43 3.82 5.23 6.62 8.01 9.41 10.8 | 166 163 162 161 160 159 158 157 | 2.91 4.30 5.71 7.10 8.50 9.89 11.3 12.6 | 166 164 163 162 162 161 160 159 | 3.64 5.04 6.44 7.83 9.23 10.6 12.0 13.4 |
SN210-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 200 193 185 | 2.32 4.07 5.83 | 204 199 195 191 | 2.32 4.07 5.83 7.58 | 205 202 199 197 194 | 2.50 4.25 6.01 7.76 9.52 | 206 204 202 200 198 195 | 2.79 4.54 6.30 8.05 9.81 11.5 | 207 205 204 203 201 199 198 | 3.27 5.03 6.78 8.54 10.3 12.0 13.8 | 208 206 205 204 203 201 200 199 | 4.00 5.76 7.51 9.27 11.0 12.7 15.5 16.3 |
SN210-54 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 265 252 | 2.90 5.25 | 270 263 257 | 2.90 5.25 7.58 | 273 268 263 259 | 3.08 5.43 7.76 10.1 | 274 271 267 264 261 | 3.70 5.72 8.05 10.4 12.7 | 276 273 271 269 266 | 3.85 6.20 8.53 10.8 13.2 | 277 275 273 271 269 268 | 4.58 6.93 9.27 11.6 13.9 16.3 |
SN280-43 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 235 226 217 209 | 2.92 4.98 7.05 9.11 | 239 234 229 225 220 | 2.92 4.98 7.05 9.11 11.1 | 241 238 234 231 227 224 | 3.21 5.28 7.34 9.40 11.4 13.5 | 243 240 237 235 231 229 227 | 3.62 5.69 7.75 9.81 11.8 13.9 16.1 | 244 242 240 238 235 234 232 231 | 4.39 6.46 8.53 10.6 12.6 14.7 16.8 18.9 | 244 243 241 237 238 237 235 234 | 5.47 7.53 9.60 11.6 13.7 15.8 17.9 20.0 |
SN280-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 268 259 250 | 3.19 5.54 7.87 | 272 267 262 257 | 3.19 5.54 7.87 10.2 | 274 271 267 263 260 | 3.48 5.93 8.16 10.5 12.8 | 276 273 270 267 264 262 | 3.89 6.24 8.58 10.9 13.2 15.7 | 277 275 273 270 268 267 265 | 4.66 7.01 9.35 11.7 14.0 16.4 18.8 | 277 276 274 272 271 270 268 266 | 5.74 8.08 10.4 12.7 15.2 17.5 19.8 22.2 |
SN280-54 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 354 339 | 3.97 7.09 | 362 353 344 | 3.97 7.09 10.2 | 365 359 352 347 | 4.26 7.38 10.5 13.6 | 366 362 357 353 349 | 4.67 7.79 10.9 14.0 17.2 | 368 365 362 358 356 352 | 5.45 8.57 11.6 14.8 18.0 21.1 | 369 367 364 361 359 357 | 6.52 9.64 12.7 15.9 19.0 22.1 |
SN440-40 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 334 324 316 307 299 | 4.14 7.04 9.93 12.8 15.8 | 338 333 327 322 318 313 | 4.14 7.04 9.93 12.8 15.8 18.7 | 340 336 332 328 325 321 318 | 4.58 7.48 10.3 13.2 16.2 19.1 22.0 | 341 339 335 332 330 326 324 322 | 5.15 8.03 10.9 13.8 16.8 19.6 22.5 25.4 | 343 341 338 336 334 332 330 328 | 6.29 9.19 12.4 14.9 17.9 20.8 23.7 26.6 | 343 342 339 338 337 334 333 332 | 7.90 10.8 13.7 16.6 19.5 22.4 25.3 28.2 |
SN440-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 426 413 400 389 | 4.94 8.65 12.3 16.1 | 432 423 417 410 403 | 4.94 8.65 12.3 16.1 19.8 | 435 428 423 419 414 409 | 5.39 9.09 12.7 16.5 20.2 23.9 | 436 431 427 423 420 416 412 | 5.94 9.64 13.3 17.1 20.8 24.4 28.1 | 438 434 431 428 426 423 420 418 | 7.09 10.8 14.4 18.2 21.9 25.6 29.3 33.0 | 438 435 434 431 429 427 425 423 | 8.71 12.4 16.2 19.8 23.5 27.2 30.9 34.6 |
SN440-52 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 494 473 453 | 5.60 9.95 14.3 | 504 492 481 469 | 5.60 9.95 14.3 18.7 | 509 499 492 483 476 | 6.04 10.4 14.7 19.1 23.5 | 511 504 498 491 486 480 | 6.59 10.9 15.3 19.7 24.0 28.3 | 514 508 504 499 496 491 488 | 7.74 12.1 16.5 20.8 25.2 29.5 33.8 | 515 511 508 504 501 497 495 491 | 9.36 13.7 18.1 22.4 26.8 31.1 35.4 39.8 |
SN440-54 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 554 533 | 6.10 10.9 | 563 552 540 | 6.10 10.9 15.9 | 568 559 551 543 | 6.54 11.4 16.3 21.1 | 570 564 557 551 545 | 7.09 11.9 16.8 24.7 26.5 | 573 568 563 559 555 551 | 8.24 13.1 18.0 22.8 27.7 32.5 | 574 571 567 564 560 557 554 | 9.86 14.7 19.6 24.4 29.3 34.1 38.9 |
SN660-40 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 522 509 497 486 475 | 6.30 10.8 15.4 19.8 24.3 | 527 520 512 506 500 493 | 6.30 10.8 15.4 19.8 24.3 28.8 | 530 525 520 514 509 505 501 | 6.93 11.4 16.0 20.5 24.9 29.4 33.9 | 531 527 523 519 515 512 508 505 | 7.70 12.2 16.8 21.2 25.7 30.2 34.7 39.2 | 533 530 527 524 521 519 516 514 | 9.44 13.9 18.5 23.0 27.4 31.9 36.4 40.9 | 534 532 529 527 524 523 520 518 | 11.7 16.3 20.8 25.2 29.7 34.2 38.7 43.2 |
SN660-44 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 588 570 554 539 | 6.90 12.0 17.2 22.2 | 596 586 576 567 558 | 6.90 12.0 17.2 22.2 27.3 | 599 592 585 579 572 565 | 7.53 12.6 17.8 22.9 27.9 33.0 | 601 596 590 586 580 575 570 | 8.30 13.4 18.6 23.6 28.7 33.8 38.9 | 603 600 595 591 588 584 581 577 | 10.0 15.2 20.3 25.4 30.4 35.5 40.6 45.7 | 605 602 598 595 592 589 587 584 | 12.3 17.5 22.6 27.6 32.7 37.8 42.9 48.0 |
SN660-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 638 621 604 589 | 7.32 12.8 18.4 23.9 | 646 635 626 616 608 | 7.32 12.8 18.4 23.9 29.4 | 649 641 635 628 622 615 | 7.95 13.4 19.0 24.5 30.0 35.5 | 651 645 640 635 630 625 619 | 8.73 14.2 19.8 25.3 30.8 36.3 41.8 | 653 649 645 641 638 634 630 627 | 10.4 16.0 21.5 27.0 32.5 38.0 43.5 49.1 | 655 651 648 645 642 639 636 634 | 12.7 18.3 23.8 29.3 34.8 40.3 45.8 51.4 |
SN660-51 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 749 721 695 | 8.35 14.9 21.5 | 762 746 730 716 | 8.35 14.9 21.5 28.0 | 768 756 745 735 724 | 8.99 15.6 22.1 28.7 35.2 | 771 762 753 746 738 730 | 9.76 16.4 22.9 29.4 36.0 42.5 | 775 768 762 755 750 745 739 | 11.5 18.1 24.6 31.2 37.7 44.2 50.9 | 777 771 766 761 757 753 748 745 | 13.7 20.4 26.9 33.4 40.0 46.5 53.1 59.7 |
SN660-54 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 856 828 | 9.26 16.8 | 868 853 837 | 9.26 16.8 24.2 | 874 863 852 841 | 8.89 17.4 24.8 32.2 | 877 869 860 852 844 | 10.6 18.2 25.6 33.0 40.4 | 881 875 869 862 856 851 | 12.4 19.9 27.3 34.7 42.2 49.7 | 883 878 873 868 863 859 854 | 14.6 22.2 29.6 37.0 44.4 52.0 59.4 |
SN940-42 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 755 732 711 691 672 | 9.11 15.6 22.2 28.7 35.2 | 767 754 743 731 721 710 | 9.11 45.6 22.2 28.7 35.2 41.7 | 772 763 754 747 739 732 724 | 10.0 16.5 23.0 29.6 36.1 42.6 49.1 | 775 768 761 755 750 744 739 733 | 11.0 17.5 24.1 30.6 37.1 43.6 50.2 56.7 | 777 772 768 764 760 756 752 749 | 13.4 20.0 26.5 33.0 39.5 46.1 52.6 59.1 | 779 775 772 769 766 763 760 757 | 16.5 23.1 29.6 36.1 42.6 49.2 55.7 62.2 |
SN940-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 912 889 868 848 | 10.4 18.3 16.2 34.0 | 921 907 896 883 872 | 10.4 18.3 16.2 34.0 41.8 | 926 916 906 899 889 882 | 11.3 19.2 27.1 34.9 42.7 50.7 | 929 921 913 907 901 894 888 | 12.3 20.3 28.1 35.9 43.8 51.7 59.5 | 931 925 920 916 911 906 901 897 | 14.8 22.7 30.5 38.4 46.2 54.1 62.0 69.8 | 933 928 924 920 917 913 909 905 | 17.8 25.8 33.6 41.4 49.4 57.2 65.0 72.9 |
SN940-50 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 1025 988 955 | 11.5 20.5 29.4 | 1042 1020 1000 981 | 11.5 20.5 29.4 38.3 | 1049 1034 1019 1006 992 | 12.4 21.4 30.3 39.2 48.1 | 1053 1042 1030 1020 1010 1000 | 13.4 22.4 31.3 40.3 49.3 58.2 | 1058 1049 1041 1034 1026 1019 1012 | 15.9 24.9 33.8 42.7 51.7 60.6 69.5 | 1060 1053 1047 1041 1035 1029 1024 1018 | 19.0 27.9 36.9 45.8 54.8 63.7 72.6 81.5 |
SN940-54 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 1205 1168 | 13.0 23.5 | 1221 1199 1179 | 13.0 23.5 33.9 | 1228 1213 1198 1185 | 13.9 24.4 34.8 45.2 | 1232 1221 1209 1199 1189 | 14.9 25.4 35.8 46.3 56.8 | 1237 1228 1220 1213 1205 1197 | 17.4 27.9 38.3 48.8 59.2 69.6 | 1239 1232 1226 1220 1213 1207 1202 | 20.5 30.9 41.4 51.9 62.3 72.7 83.2 |
SN1300-38 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 902 881 862 843 826 | 11.3 19.0 26.7 34.5 42.2 | 913 902 891 881 871 861 | 11.3 19.0 26.7 34.5 42.2 49.9 | 918 909 902 894 887 881 874 | 12.5 20.2 28.0 35.7 43.4 51.2 58.9 | 920 914 908 903 897 892 887 882 | 13.8 21.5 29.2 37.0 44.7 52.4 60.2 67.9 | 923 918 914 911 907 903 900 896 | 17.3 25.0 32.8 40.5 48.2 56.0 63.7 71.4 | 924 921 918 915 912 909 907 904 | 21.2 29.0 36.7 44.4 52.2 59.9 67.6 75.4 |
SN1300-42 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 1074 1046 1019 994 | 12.8 22.0 31.3 40.5 | 1090 1074 1059 1045 1032 | 12.8 22.0 31.3 40.5 49.8 | 1096 1085 1074 1064 1054 1045 | 14.4 23.3 32.5 41.8 51.0 60.3 | 1099 1091 1083 1075 1068 1061 1054 | 15.3 24.5 33.8 43.0 52.3 61.5 70.8 | 1103 1097 1091 1086 1081 1076 1071 1067 | 18.8 28.1 37.3 46.6 55.8 65.1 74.3 83.6 | 1104 1100 1096 1092 1088 1084 1081 1077 | 22.8 32.0 41.3 50.5 59.8 69.0 78.3 87.5 |
SN1300-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 1254 1226 1199 1174 | 14.3 25.1 35.9 46.6 | 1266 1249 1233 1218 1204 | 14.3 25.1 35.9 46.6 57.5 | 1272 1260 1248 1237 1225 1215 | 15.6 26.4 37.1 47.9 58.7 69.5 | 1275 1266 1257 1247 1239 1231 1223 | 16.9 27.6 38.4 49.2 60.0 70.7 81.5 | 1279 1272 1265 1258 1252 1246 1240 1235 | 20.4 31.2 41.9 52.8 63.5 74.3 85.1 95.9 | 1280 1275 1270 1264 1259 1254 1250 1244 | 24.4 35.1 45.9 56.7 67.5 78.2 89.1 100 |
SN1300-54 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 1659 1613 | 17.9 32.2 | 1679 1651 1627 | 17.9 32.2 46.5 | 1688 1668 1650 1632 | 19.2 33.5 47.8 62.2 | 1694 1678 1664 1650 1637 | 20.4 34.7 49.1 63.4 77.7 | 1699 1688 1678 1668 1658 1649 | 24.0 38.3 52.7 67.0 81.3 95.7 | 1702 1693 1685 1677 1669 1662 1654 | 27.9 42.2 56.6 70.9 85.3 99.6 114 |
SN1700-42 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 1441 1406 1373 1343 1313 1284 1256 1228 | 17.2 29.5 41.9 54.3 66.7 79.0 91.4 104 | 1460 1441 1422 1405 1388 1372 1357 1341 | 17.2 29.5 41.9 54.3 66.7 79.0 91.4 104 | 1468 1454 1441 1428 1417 1405 1394 1383 | 18.6 31.0 43.4 55.8 68.1 80.5 92.9 105 | 1472 1461 1451 1442 1433 1424 1416 1408 | 20.8 32.5 44.9 57.3 69.7 82.0 94.4 107 | 1476 1469 1462 1455 1449 1443 1437 1432 | 24.9 37.2 49.6 62.0 74.4 86.4 99.1 111 | 1478 1473 1467 1463 1458 1453 1449 1445 | 30.1 42.4 51.8 67.2 79.6 91.9 104 117 |
SN1700-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 1676 1641 1608 1578 1548 1519 1491 | 19.2 33.5 47.9 62.3 76.6 91.1 105 | 1690 1669 1649 1630 1612 1594 1578 1560 | 19.2 33.5 47.9 62.3 76.6 91.1 105 119 | 1698 1682 1668 1653 1640 1627 1614 1602 | 20.7 35.0 49.5 63.8 78.1 92.6 107 121 | 1702 1689 1678 1667 1656 1646 1636 1627 | 22.2 36.6 51.0 65.3 79.7 94.1 108 122 | 1706 1697 1689 1680 1672 1665 1657 1650 | 26.9 41.3 55.7 70.0 84.5 98.8 113 127 | 1708 1701 1693 1688 1681 1674 1669 1663 | 32.1 46.5 60.9 75.2 89.7 104 118 132 |
SN2200-42 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 1879 1836 1797 1760 1724 1689 1655 1621 | 22.4 38.5 54.6 70.7 86.8 103 119 135 | 1902 1878 1856 1835 1815 1796 1777 1758 | 22.4 38.5 54.6 70.7 86.8 103 119 135 | 1911 1894 1879 1864 1849 1836 1822 1809 | 24.2 40.3 56.4 72.5 88.6 105 121 137 | 1916 1903 1891 1880 1869 1859 1849 1839 | 26.0 42.1 58.2 74.3 90.4 107 123 139 | 1921 1912 1904 1896 1889 1882 1875 1868 | 32.6 47.7 63.8 79.9 96.0 112 128 144 | 1924 1917 1911 1905 1899 1894 1888 1883 | 38.2 54.3 70.4 86.5 103 119 135 151 |
SN2200-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 2177 2134 2095 2058 2022 1987 1953 | 24.9 43.5 62.1 80.7 99.2 118 136 | 2200 2176 2154 2133 2113 2094 2075 2056 | 24.9 43.5 62.1 80.7 99.2 118 136 153 | 2209 2092 2177 2162 2147 2143 2120 2107 | 26.7 45.3 63.9 82.4 101 120 138 155 | 2214 2201 2189 2178 2167 2157 2147 2137 | 28.5 47.1 65.7 84.3 103 121 140 159 | 2219 2210 2202 2194 2187 2180 2173 2166 | 34.1 52.7 71.3 89.8 108 127 146 164 | 2222 2215 2209 2203 2197 2192 2186 2181 | 40.7 59.3 77.9 96.4 115 134 152 171 |
SN2900-40 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 2786 2726 2671 2618 2568 2519 | 33.4 57.2 81.1 105 129 153 | 2818 2785 2754 2725 2697 2669 2642 2616 | 33.4 57.2 81.1 105 129 153 176 200 | 2831 2807 2785 2764 2745 2725 2706 2688 | 35.9 59.8 83.6 107 131 155 179 203 | 2838 2820 2803 2788 2772 2758 2743 2729 | 38.9 62.8 86.6 110 134 158 182 206 | 2845 1833 2822 2811 2801 2791 2781 2772 | 48.1 72.0 95.8 120 143 167 191 215 | 2848 2839 2830 2822 2814 2807 2799 2792 | 56.9 80.8 105 128 152 176 200 224 |
SN3600-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 3486 3426 3371 3318 3268 | 39.2 68.9 98.6 128 158 | 3518 3485 3454 3425 3397 3369 3342 3316 | 39.2 68.9 98.6 128 158 188 217 247 | 3531 3507 3485 3464 3445 3425 3406 3388 | 41.8 71.4 101 131 160 190 220 249 | 3538 3520 3503 3488 3472 3456 3443 3429 | 44.8 74.4 104 134 163 193 223 252 | 3545 3532 3521 3510 3500 3490 3480 3470 | 54.0 83.6 113 143 173 202 232 262 | 3548 3539 3530 3522 3514 3507 3499 3492 | 62.8 92.5 112 152 181 211 242 270 |
SN5300-46 | 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 | 5246 5166 5092 4955 | 62.2 107 151 196 240 | 5290 5245 5204 5165 5127 5091 5055 5020 | 62.2 107 151 196 240 285 329 374 | 5306 5274 5245 5217 5190 5164 5139 5114 | 67.3 112 156 201 246 290 355 379 | 5315 5291 5269 5248 5228 5208 5189 5170 | 72.5 117 162 206 251 295 340 384 | 5324 5308 5293 5278 5264 5251 5237 5224 | 90.1 135 179 224 268 313 357 40 | 5329 5317 5305 5294 5284 5274 5263 5254 | 107 152 196 241 285 330 374 419 |
